Uneven applications cost you valuable time and money, not to mention unhappy clients. Check your fluid levels with just a glance with new white tanks. This model is also designed to work seamlessly on any sized property. And as a Toro owner, you'll have access to nearly 3,000 servicing dealers across the U.S. and Canada ready to assist you. Count on it.
- Easy Fluid Check - Check your fluid levels with just a glance with new white tanks.
- One Size Fits All - Save on equipment costs since this sprayer is also designed to work seamlessly on any sized property.
- Simplified Steering - Control forward/reverse and left/right steering.
- Ride in Style - Custom-stitched seat pad with Toro bullhorn logo.
|
Easy Fluid Check
Easily check fluid levels with new white tanks.
|
|
Large Capacity
Maximize ground coverage and reduce re-fill stops with two 15-gallon spray tanks, 220 lb. hopper capacity, and a 5-gallon fuel tank.
|
|
Simplified Steering
Make adjustments on the fly with one hand with control forward/reverse and left/right steering.
|
|
Foot Button
Quick on and off for easy spot spraying.
|
|
Ride in Comfort
Ride in comfort and reduce operator fatigue with suspension in the foot plate.
|
|
Onboard Spray Hose
Ensure everything is covered with onboard spray hoses for spot spraying.
|
|
Commercial Grade Hydraulic Pumps and Wheel Motors
Developed for precise turf applications and ultimate longevity.
|
|
Ride in Style
Ride in style with a custom-stitched hip pad featuring Toro's bullhorn logo.
|
|
Fertilizer Trays
Carry up to 100 lbs of additional fertilizer with 2 fertilizer trays (50 lbs per tray).
|
Specifications
Deflector Shield |
Stainless Steel |
Engine |
Vanguard Commercial 16HP 479cc |
Engine Brand |
Vanguard |
Engine Displacement (cc) |
479 cc |
Engine Horsepower |
16.0 hp |
Engine Orientation |
Horizontal |
Fertilizer Capacity |
320 lbs |
Fuel Capacity |
5 gal. / 18.9 L / 20 Qt. |
Fuel Type |
Gasoline |
Ground Speed |
Up to 8.0 mph / 12.8 kph |
Hopper Capacity |
220 lbs |
Pump Capacity |
7 GPM |
Spinner Motor |
Hydraulic |
Spot Spray Hose |
75 ft Coil Hose |
Spray Capacity (gallons) |
60 |
Spray Width |
2 ft, 6 ft, 8 ft or 10 ft / 0.6 m, 1.8 m, 2.4 m or 3.0 m |
Spreader Hopper Capacity (lbs) |
220 |
Spreading Width |
Adjustable from 3 ft to 25 ft / 0.9 m to 7.6 m |
Start Type |
Electric |
Transmission |
Pump and Wheel Motor |
|
