Standard Feature |
Available Options |
| Axles |
2 - 8,000# Premium, Cambered Axles with Oil Bath and Valcrum Caps |
|
| Brakes |
Forward Self-Adjusting Electric Brakes on Both Axles |
|
| Suspension |
Multi-Leaf Slipper Spring w/ Equalizer |
|
| Tongue |
10" I-Beam Neck |
|
| Coupler |
Round Adjustable Pin 2-5/16” Gooseneck Coupler |
|
| Safety Chains |
3/8" Grade 70 w/ Safety Latch Hook (2 ea) |
|
| Jack |
Dual 12,000# Drop-Leg Jack (Side Wind) |
Dual 2-Speed Landing Gear |
| Frame |
8" I-Beam (10#) |
|
| Cross-Members |
3" Channel on 16" Centers |
|
| Floor |
7 Gauge Smooth Steel |
|
| Fenders |
9" x 72" 14 Ga. Diamond Plate Double Broke |
|
| Ramps |
Not Included |
6.5’ Slide In Ramp Package |
| Stake Pockets |
Stake Pockets Along Both Sides (Quantity Varies by Length) |
|
| Trailer Plug |
7-Way RV |
|
| Lights |
Recessed, Grommet-Mounted L.E.D. Lighting |
|
| Wiring |
Sealed, Modular Cold-Weather Wiring Harness |
|
| Tires |
ST215/75 R-17.5 Load Range H Radial Tires |
|
| Bolt Pattern |
8-Lug |
|
| Wheels |
Black Mod Steel |
|
| Spare Mount |
Side Spare Tire Mount |
|
| Spare Tire |
Not Included |
Spare Tire & Wheel (ST215/75 R-17.5 LR-H) |
| Paint Type |
Professional Finish w/ Primer Standard |
|
| Paint Color |
Black |
|
| Tie-Downs |
(4) 1/2" D-Rings Inside Bed to Secure Equipment Along Sides and Rear for Cargo Control |
|
| Break-Away Kit |
Complete Breakaway System w/ Zip Breakaway Cable |
|
| Battery |
12V Deep Cycle |
|
| Charger |
5A 110V on Board Battery Charger |
|
| Deck On Neck |
Not Included |
Removable Deck on the Neck- Bolt On (8' W x 6' L) |
| Gate |
Rear Combo Gate (Barn Doors & Spreader Gate) |
|
| J-Hooks |
Along sides and rear for Cargo Control |
|
| Power |
Power Up/Power Down & Gravity Down Hydraulic Pump |
- 5 Watt Solar Charger
- Wireless Remote
|
| Ram |
Self-Contained Scissor |
|
| Sides |
24" Tall (10 Ga) with formed Channel Supports |
- 3' Solid Sheet Metal Sides
- 4' Solid Sheet Metal Sides
|
| Stabilizers |
Rear Stabilizer Stands |
|
| Steps |
Convenient Side-Step to Access Top Rail |
|
| Storage |
Lockable Pump and Battery Box mounted between front Jacks |
|
| Tarp |
Fully-Formed Tarp Shroud with Tarp & Rear Tarp Rod Holders |
|
| Top Rail |
3"x 2" Rectangular Tubing |
|
| Steps & Handles |
Convenient Side-Step to Access Top Rail |
|
