When you need a jack of all trades that’s a master of all your equipment hauling needs, the 10ET Pro Series Tandem Axle Equipment Trailer won’t let you down. It brings excellent durability to the table when you’re hauling light and medium duty equipment and features an 83”-wide deck, so the possibilities are nearly endless. And it’s designed for safety and performance down to the last bolt, whether you’re driving or loading. It’s got forward self-adjusting brakes for easier brake maintenance, plus a cleated dovetail design so you can confidently load equipment without slipping. When you combine innovation, durability, and versatility, this trailer is what you get.
|
Standard Feature |
Available Options |
| Axles |
2 - 5,200# Premium, Cambered Axles with Quick-Lubricating Hubs |
|
| Brakes |
Forward Self-Adjusting Electric Brakes on Both Axles |
|
| Suspension |
Multi-Leaf Slipper Spring w/ Equalizer |
|
| Coupler |
Adjustable Forged 2-5/16” |
Adjustable Pintle in Channel in Lieu of Coupler |
| Safety Chains |
1/4" Grade 70 w/ Safety Latch Hook (2 ea) |
|
| Jack |
8,000# Set-Back, Drop-Leg Jack |
|
| Frame |
5" Channel |
|
| Cross-Members |
3" Channel |
|
| Front Stop Rail |
3/16" Fabricated Front Stop Rail |
|
| Floor |
APEX Fortified Lumber |
Blackwood Pro Rubber Infused Lumber Floor (per linear foot) 1/8” Diamond Plate Steel Floor (Per Square Foot) |
| Fenders |
Tear Drop Removable |
|
| Ramps |
4’ Tall, Channel Knee Ramps |
- 5’ Rear Slide In Ramps (Straight Deck w/ Stabilizers)
- 3’ Mega Ramps
|
| Dovetail |
3' Cleated Dovetail |
|
| Stake Pockets |
Stake Pockets Along Both Sides (Quantity Varies by Length) |
|
| Trailer Plug |
7-Way RV |
|
| Lights |
Recessed, Grommet-Mounted L.E.D. Lighting |
|
| Wiring |
Sealed, Modular Cold-Weather Wiring Harness |
|
| Tires |
ST225/75 R-15 Load Range D Radial Tires |
|
| Bolt Pattern |
6-Lug |
|
| Spare Mount |
Front Spare Tire Mount |
|
| Spare Tire |
Not Included |
Spare Tire & Wheel (ST225/75 R-15 LR-D) |
| Paint Type |
Professional Finish w/ Primer Standard |
|
| Paint Color |
Black |
- Red
- Grey
- White
- Desert Tan
- Jet Blue
- Slime Green
- Implement Green
- Equipment Orange
- Medium Yellow
|
| Rubrail |
Rub Rail Along Both Sides |
|
| Tie-Downs |
(6) 5/8" D-Rings |
- Extra 5/8" D-Rings
- Recessed D-Ring in Floor (Steel Floor Only)
|
| Break-Away Kit |
Complete Breakaway System w/ Zip Breakaway Cable |
|
| MODEL |
10ET-18KR |
| PULL TYPE |
Bumperpull |
| GVWR |
9990 lbs |
| GAWR (EA. AXLE) |
5200 lbs |
| EMPTY WEIGHT |
2420 lbs |
| CARGO CAPACITY |
7570 lbs |
| BED LENGTH |
16' |
| BED WIDTH |
83" |
| A |
217-1/2" |
| B |
127" |
| C |
90-1/2" |
| Tongue Length |
56-3/4" |
| MODEL |
10ET-20KR |
| PULL TYPE |
Bumperpull |
| GVWR |
9990 lbs |
| GAWR (EA. AXLE) |
5200 lbs |
| EMPTY WEIGHT |
2520 lbs |
| CARGO CAPACITY |
7470 lbs |
| BED LENGTH |
18' |
| BED WIDTH |
83" |
| A |
240" |
| B |
138" |
| C |
102" |
| Tongue Length |
56-3/4" |
