Bring your low-profile equipment hauling to new heights with the 14OT Heavy Duty Over-the-Axle Tilt Bed Equipment Trailer. It’s unlike any of our other trailers, highlighted by a scissor-style hydraulic hoist that offers stability, energy efficiency, and less maintenance than other systems. With a rear knife edge, a full 96”-wide tilt platform, and a winch mount plate at the front of the platform, you can take your productivity into overdrive with this over-the-axle workhorse.
|
Standard Feature |
Available Options |
| Axles |
2 - 7,000# Premium, with Quick-Lubricating Hubs |
|
| Brakes |
Forward Self-Adjusting Electric Brakes on Both Axles |
|
| Suspension |
Multi-Leaf Slipper Spring w/ Equalizer |
|
| Coupler |
Adjustable 2-5/16” Demco EZ Latch, Round Adjustable Pin 2-5/16” on Gooseneck Model |
Adjustable Pintle in Channel in Lieu of Coupler |
| Safety Chains |
3/8" Grade 70 w/ Safety Latch Hook (2 ea) |
|
| Jack |
12,000# Drop-Leg Jack (Side Wind) Dual Jacks on Gooseneck Model |
12,000# Elec/Hyd. Jack BY Stillwell™ Dual Elec/Hyd 12,000# Jacks by Stillwell™ Dual Single-Speed Drop-Leg Jacks Dual 2-Speed Landing Gear |
| Frame |
8" I-Beam, 10# / 13# on 26' Models |
|
| Cross-Members |
3" Channel |
|
| Front Stop Rail |
3/16" Fabricated Front Stop Rail (Bumper Pull Only) |
|
| Floor |
APEX Fortified Lumber |
Blackwood Pro Rubber Infused Lumber Floor (per linear foot) |
| Stake Pockets |
Stake Pockets Along Both Sides (Quantity Varies by Length) |
|
| Trailer Plug |
7-Way RV |
|
| Lights |
Recessed, Grommet-Mounted L.E.D. Lighting |
|
| Wiring |
Sealed, Modular Cold-Weather Wiring Harness |
|
| Tires |
ST235/80 R-16 Load Range E Radial Tires |
Tire Upgrade (ST235/80 R-16 LR-G) |
| Bolt Pattern |
8-Bolt |
|
| Spare Mount |
Front Spare Tire Mount |
|
| Spare Tire |
Not Included |
Spare Tire & Wheel (ST235/80 R-16 LR-E) Spare Tire Upgrade (ST235/80 R-16 LR-G) |
| Paint Type |
Professional Finish w/ Primer Standard |
|
| Paint Color |
Black |
Red
Grey
White
Desert Tan
Jet Blue
Slime Green
Implement Green
Equipment Orange
Medium Yellow |
| Tilt Deck Dimensions |
102" Wide with 1/4" Diamond plate Knife Edge |
|
| Tilt Deck Operation |
Power Up/Power Down with Hydraulic System |
|
| Rubrail |
Rub Rail Along Both Sides |
|
| Tie-Downs |
|
Extra 5/8" D-Rings |
| Break-Away Kit |
Complete Breakaway System w/ Zip™ Breakaway Cable and Charger |
|
| Power |
Power Up/Power Down & Gravity Down Hydraulic Pump |
|
| Tilt Deck Angle |
16° |
|
| Winch Plate |
Front Mounted Steel Winch Plate |
|
| Model |
14OT-26GN |
14OT-26 |
14OT-24GN |
14OT-24 |
14OT-22GN |
14OT-22 |
| Pull Type |
Bumperpull |
Bumperpull |
Bumperpull |
Bumperpull |
Bumperpull |
Bumperpull |
| GVWR |
14000 lbs |
14000 lbs |
14000 lbs |
14000 lbs |
14000 lbs |
14000 lbs |
| GAWR (Ea. Axle) |
7000 lbs |
7000 lbs |
7000 lbs |
7000 lbs |
7000 lbs |
7000 lbs |
| Empty Weight |
5155 lbs |
5290 lbs |
5175 lbs |
4950 lbs |
4970 lbs |
4745 lbs |
| Cargo Capacity |
8845 lbs |
8710 lbs |
8825 lbs |
9050 lbs |
9030 lbs |
9255 lbs |
| Bed Length |
26' |
26' |
24' |
24' |
22' |
22' |
| Bed Width |
102" |
102" |
102" |
102" |
102" |
102" |
| A |
312" |
312" |
288" |
288" |
264" |
264" |
| B |
171" |
171" |
159" |
159" |
141" |
141" |
| C |
141" |
141" |
129" |
129" |
123" |
123" |
| Tongue Length |
96-1/8" |
73-3/8" |
96-1/8" |
73-3/8" |
96-1/8" |
73-3/8" |
